Control Arms Front

Adjustable lower control arms (lower wishbone)



Fits
Porsche 986 Boxster - Front and Rear
Porsche 996, 997 - Front and Rear
Porsche 991 - Front Only
Porsche 987 Boxster and Cayman - Front and Rear
Porsche 981 Boxster and Cayman - Front and Rear
Porsche 718 Boxster and Cayman - Front and Rear

Set of 2 x Adjustable lower control arms - 1 pair, required per axle

Elephant Racing adjustable lower control arms provide the camber, caster and precision you need. Length adjustable similar to the factory GT3 control arms, but without the need for shims.

Quick and Easy Adjustments – No need to keep a stock of shims on hand, length is easily adjusted by rotating the center hex head. Rotate clockwise to expand or counter-clockwise to contract the arm length.Adjustments can be made within minutes. No shims to mess with. Perfect setup to make quick changes for the track.

Widen Track – Use in combination with our camber plates on the front, or our adjustable length arms upper control arms on the rear to widen the track. This allows you to achieve a wider track without altering the scrub radius as happens when using wheel spacers.

Heim Joint – Our spherical bearings eliminate the deflection associated with rubber bushings. These bearings maintain stable suspension alignment, and improve feedback.

Fully Weather Sealed – Proper boots at both the ball joint and heim joint ends to keep water and contaminants out for extended life. These arms are suitable for extended road and track use.

Camber Adjustment – Extended range of adjustment lets you achieve aggressive camber. Or you can dial it back to get a factory street alignment on lowered cars.

Caster Adjustment – Our Caster Adjuster allows you to tune this important setting that the factory left out. A must-have for cars that have extended lower control arms to correct for un-intended caster change that is caused by the extended arms. Rotate the center puck and bolt down to secure the setting.

The arms are fully rebuildable with replaceable heim and ball joints.

On 996, 997, & 991 Cars:
Center puck can be also used as a wheelbase adjuster on the rear to draw the wheels back to improve weight distribution. It is a great tuning aid for adjusting out understeer

Litronic Bracket – This bracket is required for cars that are originally equipped with the litronic headlights. This adapter bracket attaches to the headlight angle sensor.


Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

2180001

The product you are viewing cross references to these numbers

Featuring an analogue (no fiddly shims used here) The settings can be simply achieved with the arm pre-fitted to the vehicle and adjusted without the need for any special tools.

Caster adjustment range of ±1.25° on the front, and ±13mm Setback on the rear.



PRICE IS FOR A SET OF 2.

Currently these arms fit the following models
• 996 FRONT OR REAR (inc GT3)
• 986 FRONT
• 997 FRONT OR REAR


• Made from Forged 6061-T6 aluminium for maximum strength and at a minimum weight point.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

572630K

The product you are viewing cross references to these numbers

RSS Lower control arm kit for Porsche Models.
Type: None Adjustable Thrust Arm Bushing



RSS Tarmac Series Motorsport Lower Control Arms are specifically engineered for use on lowered vehicles that have reduced travel struts/dampers such as PASM or M030 option. Alternatively if the car is equipped with high quality aftermarket or motorsport coilover kits ie Bilstein PSS10, KW V3 or Ohlins etc.

The Lower Control Arms are NOT COMPATIBLE with "Base Model Suspension" (long travel struts/dampers) or "Base Model struts/dampers with lowering springs."
Caution: Do not install on vehicles with Base Model struts/dampers as it may result in an unsafe driving condition with possibility of suspension bind when struts/dampers are fully extended or in full drop.

Price: Set of Two Control Arms plus 2 x 1mm/2mm/3mm/7mm Shims.

RSS Tarmac Series Control Arms are manufactured from 6061 aerospace grade billet aluminum. This allows for a more uniform molecular structure
at every point of the arm over the cast motorsports arm giving the customer a more durable and inherently stronger part. Manufacturing from billet
aluminum rather than casting results in less impurities in the metal.

• Completely serviceable - for the extreme, repetitive track-day participant, our high-strength steel alloy spherical bearings (with a friction reducing /longevity increasing Teflon liner) can be replaced unlike the motorsports arm, in which case the customer will have to buy a new set of arms if the spherical bearings are worn.
Additionally, anodized surfaces and zinc-plated steel parts allow for better corrosion resistance against the elements.

• Adjustable suspension geometry - adjust dynamic camber values and roll center heights with our unique zinc-plated steel bushings.

• Solid monoball control arm ends offer a more responsive suspension over the factory one-piece rubber-injected control arm (also uses the same high
strength steel alloy spherical bearing found in our control arm monoball kit).

• Unique design provides more gusseting over the motorsports arms for added strength and aesthetically appealing looks.

Please Check Fitting Guide Before Ordering Click Here

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

356

The product you are viewing cross references to these numbers

Track control arms with adjustable bushings.



Fitted with Black 95A material for both bushes for ultimate performance and is supplied with an offset outer sleeve and CNC machined inner sleeve to allow for on-car adjustment of both caster and camber, for quick and easy optimisation of your wheel alignment.  (tools or spanner not included)  These arm features suspension geometry tuning, with a caster increase of up to 0.4° and camber adjustment of +/- 0.75°

OEM Part Number: 98133105301, 99733104180, 99634105319

Fits:

FRONT
Porsche 997 GT2, GT3 & GT3RS
Porsche 986 Boxster (1997-2004)
Porsche 996 (1997-2005)

REAR
Porsche 997 GT2, GT3 & GT3RS
Porsche 997 incl. Turbo
Porsche 718 Boxster/Cayman
Porsche 981 Boxster/Cayman
Porsche 986 Boxster (1997-2004)
Porsche 987 Boxster (2005-2012)
Porsche 987C Cayman (2005 - 2012)
Porsche 996 (1997-2005)

Please note: you will need 997 front fork arms to accommodate the adjustable bushes as they are wider than standard bush.
When you add this item to the basket you will be prompted with mandatory product you will need to add as well.

Both Adjustable and Non-Adjustable bush options are available to suit differing driving and performance requirements.

Please click 'Zoom in' to view the diagram (No 21)

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

3602409961G

The product you are viewing cross references to these numbers
