EFI Throttle Body Kit Black Anodized “R” Finish. Porsche 911 / 964 / 993 / 914-6  ❭  PM-O94

PMO EFI Throttle Body Kit – Black Anodized “R” Finish – 40mm / 46mm / 50mm

Upgrade your classic air-cooled Porsche to modern electronic fuel injection with the PMO EFI Throttle Body Kit, available in 40mm, 46mm and 50mm sizes with the distinctive Black Anodized “R” finish.

Fits

• Porsche 911 1965-1968 2.0L / 912 SWB (F)
• Porsche 911 1968-1973 2.2L / 2.4L / 2.7L RS LWB (F)
• Porsche 911 1974-1977 2.7L / 1976-77 3.0 Carrera
• Porsche 911 1978-1983 3.0L / SC
• Porsche 911 1984-1986 3.2L
• Porsche 911 1987-1989 3.2L G50
• Porsche 964 (911) C2 1989-93
• Porsche 964 (911) C4 1989-93
• Porsche 993 (911) C2 1994-97
• Porsche 993 (911) C4 1994-97
• Porsche 993 (911) C2S 1994-97
• Porsche 993 (911) C4S 1994-97
• Porsche 914-6 (1970-1976)

Designed for air-cooled six-cylinder Porsche engines from 1965 to 1998, PMO individual throttle bodies combine the classic appearance and response of traditional carburettors with the accurate fuel control and tuning possibilities of modern EFI.

The Black Anodized “R” finish gives the throttle bodies a purposeful vintage competition appearance, making them particularly suited to performance, restomod and motorsport-inspired Porsche engine builds.

Inlet Manifolds, Fuel Injectors and Throttle Position Sensor (TPS) are Not Included

Please note that inlet manifolds, fuel injectors and the TPS shown in product imagery are for reference and are not included with the kit.

What Does the PMO EFI Throttle Body Kit Do?

PMO individual throttle bodies replace carburettors or the existing induction system as part of a complete electronic fuel injection conversion.

Each cylinder receives its own throttle bore, providing direct and responsive airflow. Fuel is delivered through individual injectors controlled by a compatible programmable ECU.

When correctly installed and tuned, benefits can include:

• Sharper throttle response
• Precise electronic fuel control
• Improved engine tuneability
• Better cold starting and driveability
• Accurate control of air/fuel ratios
• Potential improvements in performance and fuel efficiency
• Individual throttle response for each cylinder
• Classic competition appearance with modern EFI technology

40mm, 46mm or 50mm – Which Size?

PMO offers three throttle body sizes to suit different air-cooled Porsche engine specifications.

• 40mm – Ideal for smaller-capacity and road-focused engines where good air velocity, throttle response and low-to-mid-range performance are important.
• 46mm – Suitable for larger-capacity, fast-road and modified engines requiring increased airflow while maintaining excellent throttle response.
• 50mm – Designed for highly modified, large-capacity and competition engines where maximum airflow and high-RPM performance are required.

Correct sizing depends on engine capacity, cylinder heads, camshafts, compression ratio, intended RPM range and power requirements. Consult your engine builder when selecting the appropriate size.

Precision PMO Construction

PMO EFI throttle bodies are precision CNC machined and hand assembled in Anaheim, California using aerospace-grade materials.

Sealed ball bearings provide durability, while the one-piece throttle shaft maintains accurate alignment for smooth and consistent throttle operation.

Tapered 52mm intake throats improve airflow into the throttle bodies, while billet fuel rails accommodate Bosch-style fuel injectors.

EFI Management Compatibility

PMO EFI throttle bodies can be used with programmable engine management systems including Haltech, MegaSquirt, MoTeC and other suitable aftermarket EFI controllers.

The ECU must be correctly configured and tuned for the individual engine specification.

Injector size, fuel pressure, sensors and ECU configuration should be discussed with your engine builder or EFI system supplier before installation.

Converting from Carburettors to EFI

A carburettor-to-EFI conversion requires a suitable high-pressure fuel system in addition to the throttle bodies.

A fuel pump capable of approximately 60 psi is required. The Walbro GSL393 external universal inline fuel pump, rated at approximately 160 LPH, is one suitable option. Another correctly specified 60 psi EFI fuel pump can also be used.

Fuel lines, filters, pressure regulation and associated components must be suitable for EFI operating pressures.

• Fuel rail retaining/injector clip – 534-102
• TPS sensor – 17123852
• Bosch-style fuel injectors
• Suitable high-pressure EFI fuel pump
• Compatible programmable ECU

Fuel injector specification should be selected according to engine capacity, expected power output, fuel type and EFI system requirements.

PMO Black Anodized “R” EFI Throttle Bodies for Air-Cooled Porsche

PMO individual throttle bodies provide an excellent solution for Porsche owners wanting the immediate response and appearance of classic individual induction combined with modern electronic fuel injection.

Available in 40mm, 46mm and 50mm sizes, the system can be matched to road, fast-road, restomod and competition air-cooled Porsche flat-six engines.

The Black Anodized “R” finish provides a distinctive period motorsport appearance, making these throttle bodies particularly suited to classic Porsche 911 performance builds where engine-bay appearance is as important as performance.
